LED Floodlight High Mast 500W Stadium Luminaire Head,500W LED high mast Flood light is equivalent to 1000W Traditional Metal halide floodlight or 1000W High Pressure Sodium stadium lamps.
Main Features
Covering full ranges power from 30W to 600W for lower cost in different applications.
Multiple optical lens 25° / 55° / 90° / 120° / Type2 / Type3 / Type4 for your specific application requirement. but 120 degree is without optical.
Wattage adjustable can be setted in 4 shifts: 100% 80% 60% 40%，CCT adjustable ,only 120°(without lense) is available with CCT adjustable
Cost-effective, lightweight, ultra-thin flood lights.Light efficiency up to 190Lm/W, standard 170Lm/W.
The Floodlight made by die-cast aluminum,Luminaire back side has cooling fins to enhance the heat dissipation
Double Protection: PC Lens and Tempered Glass,PC lens anti UV, chemicals, dust etc. Smooth tempered glass enables good elf-clean.
Angle Adjustable, U type bracket and pole mounting bracket make it installation quick and easy.
the fixture coated with electrophoresis and powder for excellent anti-corrosion performance.
IP66 Waterproof and IK08 rating.
Specifications
| Product Type | LED Flood Light |
| Model No. | GL-FL-500WK |
| Power | 500W |
| Lumens | 85,000LM (SMD 2835) |
| Input Voltage | AC 100-277V 50/60Hz |
| Luminous efficiency | 170Lm/W Standard (SMD 2835), 190Lm/W Optional(SMD 5050) |
| Light Source | SMD2835 (Standard） / SMD 5050 |
| CRI | >70RA |
| KELVIN (CCT) | 3000K/4000K/5000K/5700K/6500K |
| Beam Angle | 25°/55°/90°/120°/Type2/Type3/Type4 |
| DIMMABLE | Non-dimmable / Dimmable |
| Driver Power | Moso / Sosen/Done |
| Power Factor | >0.95 |
| IP Rating | IP66 |
| Product Dimension | 560×555×76mm |
| Weight | 10.2KG(1pcs) |
| CTN Size | 605×580×130mm (1PCS/CTN) |
| Life Span | >50,000 hours |
| Warranty | 5 Years Warranty |
| Certified | CE ROHS |
Dimension
LED Floodlight High Mast 500W Stadium Luminaire Head Features
Photometrics
Multiple light distribution 25° / 55° / 90° / 120° / Type2 / Type3 / Type4 for different applications, Asymmetrical light distribution for better light directionality in applications such as tennis courts, basketball courts, volleyball, etc.
LED Floodlight High Mast 500W Stadium Luminaire Head Installation
Applications
LED Floodlight High Mast 500W Stadium Luminaire Head are widly used for better light directionality in applications such as tennis courts, basketball courts, volleyball, etc. even for stadium and billboard.
This Series LED Floodlight High Mast 500W Stadium Luminaire Head is designed to be qualified for your special requirement. Covering full ranges power from 30W to 600W with different sizes for lower cost in different applications. Most of all, it is enduring and cost-effective. Multiple light distribution for different applications , widly use for better light directionality in applications such as tennis courts, basketball courts, volleyball, etc. even for stadium and billboard. Most importantly, the price is very competitive.
Golon lighting released its newly developed led flood light based on overall market investigation, customers' feedback, This Series led flood light has become a star product among its customers because of its elegant appearance, multiple wattage coverage as well as various and perfect photometric Solution.
If you would like to purchase our led Floodlights, you can contact us by phone or by mail.
